Chemical Composition
|
Element |
Composition Limits, % |
|||||||
|
Alloy N06600 |
Alloy N06601 |
Alloy N06617 |
Alloy N06690 |
Alloy N06693 |
Alloy N06025 |
Alloy N06045 |
Alloy N06603 |
|
|
Nickel |
72.0 min |
58.0-63.0 |
44.5 min |
58.0 min |
remainderA |
remainderA |
45.0 min |
remainderA |
|
Chromium |
14.0-17.0 |
21.0-25.0 |
20.0-24.0 |
27.0-31.0 |
27.0-31.0 |
24.0-26.0 |
26.0-29.0 |
24.0-26.0 |
|
Cobalt |
... |
... |
10.0-15.0 |
... |
... |
... |
... |
... |
|
Molybdenum |
... |
... |
8.0-10.0 |
... |
... |
... |
... |
... |
|
Iron |
6.0-10.0 |
remainder |
3.0 max |
7.0-11.0 |
2.5-6.0 |
8.0-11.0 |
21.0-25.0 |
8.0-11.0 |
|
Manganese |
1 .0 max |
1.0 max |
1.0 max |
0.5 max |
1.0 max |
0.15 max |
1.0 max |
0.15 max |
|
Aluminum |
... |
1.0-1.7 |
0.8-1.5 |
... |
2.5-4.0 |
1.8-2.4 |
... |
2.4-3.0 |
|
Cartlon |
0.15 max |
0.10 max |
0.05-0.15 |
0.05 max |
0.15 max |
0.15-0.25 |
0.05-0.12 |
0.20-0.40 |
|
Copper |
0.5 max |
1.0 max |
0.5 max |
0.5 max |
0.5 max |
0.1 max |
0.3 max |
0.50 max |
|
Silicon |
0.5 max |
0.5 max |
1.0 max |
0.5 max |
0.5 max |
0.5 max |
2.5-3.0 |
0.50 max |
|
Sulfur |
0.015 max |
0.015 max |
0.015 max |
0.015 max |
0.01 max |
0.010 max |
0.010 max |
0.010 max |
|
Titanium |
... |
... |
0.6 max |
... |
1.0 max |
0.1-0.2 |
... |
0.01-0.25 |
|
Phosphorus |
... |
... |
... |
... |
... |
0.020 max |
0.020 max |
0.20 max |
|
Zirconium |
... |
... |
... |
... |
... |
0.01-0.10 |
... |
0.01-0.10 |
|
Yttrium Boron |
... |
... |
0.006 max |
... |
... |
0.05-0.12 |
... |
0.01-0.15 |
|
Nitrogen |
... |
... |
... |
... |
... |
... |
... |
... |
|
Niobium |
... |
... |
... |
... |
0.5-2.5 |
... |
... |
... |
|
Cerium |
... |
... |
... |
... |
... |
... |
0.03-0.09 |
... |
Note:
A. Element shall be determined arithmetically by difference.
Mechanical Properties of Rods and Bars
|
Condition and Diameter or Distance Between Parallel Surfaces, in. (mm) |
Tensile Strength, min, psi (MPa) |
Yield Strength (0.2 % offset), min, psi (MPa) |
Elongation in 2 in. or 50 mm or 4D, min,% |
|
UNS N06600: |
|||
|
Cold-worked (as worked): |
|
|
|
|
Rounds: |
|
|
|
|
Under 1⁄2 (12.7) |
120 000 (825) |
90 000 (620) |
7A |
|
1⁄2 to 1 (12.7 to 25.4), incl |
110 000 (760) |
85 000 (585) |
10 |
|
Over 1 to 21⁄2 (25.4 to 63.5), incl |
105 000 (725) |
80 000 (550) |
12 |
|
Squares, hexagons, and rectangles: |
|
|
|
|
1⁄4 (6.4) and under |
100 000 (690) |
80 000 (550) |
5A |
|
Over 1⁄4 to 1⁄2 (6.4 to 12.7), excl |
95 000 (655) |
70 000 (480) |
7 |
|
Hot worked (as worked): |
|
|
|
|
Rounds: |
|
|
|
|
1⁄4 to 1⁄2 (6.4 to 12.7), incl |
95 000 (655) |
45 000 (310) |
20 |
|
Over 1⁄2 to 3 (12.7 to 76.2), incl |
90 000 (620) |
40 000 (275) |
25 |
|
Over 3 (76.2) |
85 000 (585) |
35 000 (240) |
30 |
|
Squares, hexagons, and rectangles: |
|
|
|
|
All sizes |
85 000 (585) |
35 000 (240) |
20 |
|
Rings and disksB |
— |
— |
— |
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
Rods and bars, all sizes |
80 000 (550) |
35 000 (240) |
30A |
|
Rings and disksC |
— |
— |
— |
|
Forging Quality: |
|
|
|
|
All sizes |
D |
D |
D |
|
UNS N06601: |
|||
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
All products, all sizes |
80 000 (550) |
30 000 (205) |
30 |
|
Forging Quality: |
D |
D |
D |
|
UNS N06617: |
|||
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
All products, all sizes |
95 000 (655) |
35 000 (240) |
35 |
|
Forging Quality: |
D |
D |
D |
|
UNS N06690: |
|||
|
Cold-worked (as worked): |
|
|
|
|
Rounds: |
|
|
|
|
Under 1⁄2 (12.7) |
120 000 (825) |
90 000 (620) |
7A |
|
1⁄2 to 1 (12.7 to 25.4), incl |
110 000 (760) |
85 000 (585) |
10 |
|
Over 1 to 21⁄2 (25.4 to 63.5), incl |
105 000 (725) |
80 000 (550) |
12 |
|
Squares, hexagons, and rectangles: |
|
|
|
|
1⁄4 (6.4) and under |
100 000 (690) |
80 000 (550) |
5A |
|
Over 1⁄4 to 1⁄2 (6.4 to 12.7), excl |
95 000 (655) |
70 000 (480) |
7 |
|
Hot worked (as worked): |
|
|
|
|
Rounds: |
|
|
|
|
1⁄4 to 1⁄2 (6.4 to 12.7), incl |
95 000 (655) |
45 000 (310) |
20 |
|
Over 1⁄2 to 3 (12.7 to 76.2), incl |
90 000 (620) |
40 000 (275) |
25 |
|
Over 3 (76.2) |
85 000 (585) |
35 000 (240) |
30 |
|
Squares, hexagons, and rectangles: |
|
|
|
|
All sizes |
85 000 (585) |
35 000 (240) |
20 |
|
Rings and disksB |
— |
— |
— |
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
Rods and bars, all sizes |
85 000 (586) |
35 000 (240) |
30A |
|
Rings and disksC |
— |
— |
— |
|
Forging Quality: |
|
|
|
|
All sizes |
D |
D |
D |
|
UNS N06693: |
|||
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
Rods and bars, all sizes |
100 000 (690) |
50 000 (345) |
30 |
|
Forging Quality: |
|
|
|
|
All sizes |
D |
D |
D |
|
UNS N06603: |
|||
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
All products, all sizes |
94 000 (650) |
43 000 (300) |
25 |
|
Forging Quality: |
|
|
|
|
All sizes |
D |
D |
D |
|
UNS N06025: |
|
|
|
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
All products, all sizes |
98 000 (680) |
39 000 (270) |
30 |
|
Forging Quality: |
|
|
|
|
All sizes |
D |
D |
D |
|
UNS N06045: |
|
|
|
|
Cold-worked (annealed) or hot-worked (annealed): |
|
|
|
|
All products, all sizes |
90 000 (620) |
35 000 (240) |
35 |
|
Hot-worked (Annealed):E |
|
|
|
|
Rods and bars, all sizes |
75 000 (517) |
30 000 (207) |
30 |
|
Forging Quality: |
|
|
|
|
All sizes |
D |
D |
D |
Note:
A. Not applicable to diameters or cross sections under 3⁄32 in. (2.4 mm).
B. Hardness B75 to B100, or equivalent.
C. Hardness B75 to B95, or equivalent.
D. Forging quality is furnished to chemical requirements and surface inspection only. No mechanical properties are required.
E. High-temperature annealed condition.
