ASTM B167 specification covers nickel-chromium-iron alloys (UNS N06600, N06601, N06603, N06690, N06693, N06025, N06045, and N06696) and nickel-chromium-cobalt molybdenum alloy (UNS N06617) in cold-worked annealed, hot-worked annealed, and hot-finished seamless pipe and tube intended for general corrosion resistant and heat resistant applications. The material shall conform to the required chemical composition for nickel, chromium, iron, manganese, molybdenum, cobalt, aluminum, carbon, copper, boron, silicon, sulfur, titanium, niobium, phosphorous, zirconium, yttrium, and cerium. The following test methods shall be performed on the alloys, namely: chemical analysis, tension test, and hydrostatic or nondestructive electric test. The material shall conform to the required mechanical properties such as tensile strength, yield strength, elongation, nondestructive electric test, and rounding method.
Size: 6.00 mm OD up to 914.4 mm OD
Thickness: 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS
Length: Within 13500mm
Type: Seamless Pipes, Seamless Tubes
Grades: ASTM B167 UNS N06600, N06601, N06603, N06690, N06693, N06025, N06045, N06696.
Mechanical Properties
Grade Condition and Size
Tensile Strength, min, psi (MPa)
Elongation 2inches or 50.8mm or 4D min, %
Yield Strength (0.2% offset), min, psi (MPa)
Inconel 600 (UNS N06600):
Hot-Worked Annealed:
5inches(127mm) in outside diameter and under
80 000 (550
35
30 000 (205)
Over 5inches(127mm) in outside diameter
75 000 (515)
35
25 000 (170)
Cold-Worked Annealed:
5inches(127mm) in outside diameter and under
80 000 (550)
30
35 000 (240)
Over 5inches(127mm) in outside diameter
80 000 (550)
35
30 000 (205)
Chemical Properties
|
Elements |
Chemical Composition |
|
|
Inconel 600 |
Inconel 601 |
|
|
Nickel |
72.0 min |
58.0 to 63.0 |
|
Chromium |
14.0 to 17.0 |
21.0 to 25.0 |
|
Iron |
6.0 to 10.0 |
Remainder |
|
Manganese |
1.0 max |
1.5 max |
|
Carbon |
0.15 max |
0.10 max |
|
Copper |
0.5 max |
1.0 max |
|
Silicon |
0.5 max |
0.5 max |
|
Sulfur |
0.015 max |
0.015 max |
