Chemical Composition
|
Element |
Composition Limits, % |
||
|
N06625 |
N06219 |
N06650 |
|
|
Carbon |
0.10 max |
0.05 max |
0.03 max |
|
Manganese |
0.50 max |
0.50 max |
0.50 max |
|
Silicon |
0.50 max |
0.70-1.10 |
0.50 max |
|
Phosphorus |
0.015 max |
0.020 max |
0.020 max |
|
Sulfur |
0.015 max |
0.010 max |
0.010 max |
|
Chromium |
20.0 min - 23.0 max |
18.0-22 .0 |
19.0-21.0 |
|
Columbium + tantalum |
3.15 min - 4.15 max |
... |
0.05-0.50 |
|
Cobalt (if determined) |
1.0 max |
1.0 max |
1.0 max |
|
Molybdenum |
8.0 min |
7.0-9.0 |
9.5-12 5 |
|
|
10.0 max |
... |
... |
|
Iron |
5.0 max |
2.0-4.0 |
12.0-16.0 |
|
Aluminum |
0.40 max |
0.50 max |
0.05-0.50 |
|
Titanium |
0.40 max |
0.50 max |
... |
|
Copper |
... |
0.50 max |
0.30 max |
|
NickelA |
58.0 min |
Bal. |
Bal. |
|
Tungsten |
... |
... |
0.50-2.50 |
|
Nitrogen |
... |
... |
0.05-0.20 |
Note:
A. Element shall be determined arithmetically by difference
Mechanical Properties for Hot-Worked Rod and Bar and ColdWorked Rod A
|
Diameter or Distance Between Parallel Surfaces, in. (mm) |
Tensile Strength min, ksi (MPa) |
Yield Strength (0.2 % offset), min, ksi (MPa) |
Elongation in 2 in. or 50 mm or 4D, min, % |
|
UNS N06625 Grade 1 (Annealed)B |
|||
|
Up to 4 (102), incl |
120 |
60 |
30 |
|
Over 4 (102) to 10 (254), incl |
110 |
50 |
25 |
|
UNS N06625 Grade 2 (Solution Annealed)C |
|||
|
All sizes |
100 |
40 |
30 |
|
UNS N06219 All (Solution Annealed) |
|||
|
All sizes |
96 (600) |
39 (270) |
50 |
|
UNS N06650 All (Solution Annealed) |
|||
|
All sizes |
116 (800) |
58 (400) |
45 |
Note:
A. Forging quality is furnished to chemical requirements and surface inspection only. No tensile properties are required. Forging stock is typically supplied in the hot worked condition, (see X1.1.5).
B. Annealed 1600°F (871°C) minimum.
C. Solution annealed at 2000°F (1093°C) minimum, with or without subsequent stabilization anneal at 1800°F (982°C) minimum to increase resistance to sensitization.
