We are committed to providing one-stop service for steel pipe products to customers around the world.
ASTM A53 is a carbon steel alloy, which can
be used as structural steel or for low-pressure pipelines.
ASTM A53 (ASME SA53) carbon steel pipe is a
specification that covers seamless and welded black and hot-dipped galvanized
steel pipe in NPS 1/8″ to NPS 26. A 53 is intended for pressure and mechanical
applications and is also acceptable for ordinary uses in steam, water, gas, and
air lines.
Outer Diameter: 10.3 mm (1/8 inch) to 660
mm (26 inch)
Wall Thickness: 3mm-12mm
Schedule: 10, 40, STD, XS, to XXS
Sizes: 1/2” to 20”
Mechanical Composition:
Grade A
Grade B
Tensile Strength, min., psi, (MPa)
48,000 (330)
60,000 (415)
Yield Strength, min., psi, (MPa)
30,000 (205)
35,000 (240)
Chemical Composition:
/
Grade
C,
max
Mn,
max
P,
max
S,
max
Cu*,
max
Ni*,
max
Cr*,
max
Mo*,
max
V*,
max
Type S (Seamless)
A
0.25
0.95
0.05
0.05
0.4
0.4
0.4
0.15
0.08
B
0.3
1.2
0.05
0.05
0.4
0.4
0.4
0.15
0.08
Type E (Electric-resistance Welded)
A
0.25
0.95
0.05
0.05
0.4
0.4
0.4
0.15
0.08
B
0.3
1.2
0.05
0.05
0.4
0.4
0.4
0.15
0.08
Type F (Furnace-welded)
A
0.3
1.2
0.05
0.05
0.4
0.4
0.4
0.15
0.08
