Standard Stainless Steel 254SMO (UNS S31254) super austenitic pipes are widely deployed in severe industrial environments, including marine engineering, offshore oil & gas production, reverse osmosis desalination, pulp and paper bleaching plants, and flue gas desulfurization (FGD) scrubbers. The 6% Mo addition paired with high nitrogen content gives 254SMO exceptionally high mechanical strength alongside market-leading pitting resistance.
| Product Form | Outer Diameter (OD) | Wall Thickness (WT) | Standard Length |
|---|---|---|---|
| Seamless Pipe (SMLS) | 10.3mm – 406.4mm (1/8" – 16") | 1.24mm – 40.49mm (SCH 5S – SCH 160) | 6m / 12m / Fixed Length |
| Welded Pipe (ERW / EFW) | 15.0mm – 1219.0mm (1/2" – 48") | 1.5mm – 30.0mm (SCH 5S – SCH 80S) | 6m / Cut-to-length |
| Desalination / Process Tubing | 6.0mm – 76.2mm | 0.89mm – 6.0mm | Straight 6m / Coiled |
| Element | Cr | Ni | Mo | N | Cu | C | Mn | Si | Fe |
|---|---|---|---|---|---|---|---|---|---|
| Min. | 19.5 | 17.5 | 6.00 | 0.18 | 0.50 | - | - | - | Bal. |
| Max. | 20.5 | 18.5 | 6.50 | 0.22 | 1.00 | 0.020 | 1.00 | 0.80 | Bal. |
| Tensile Strength Rm (MPa) | Yield Strength Rp0.2 (MPa) | Elongation A5 (%) | Hardness (HB) | Density (g/cm³) | PREN Index |
|---|---|---|---|---|---|
| ≥ 650 | ≥ 300 | ≥ 35 | ≤ 223 | 8.00 | ≥ 42 |
