Standard Stainless Steel 317 (UNS S31700) high-molybdenum pipes are widely employed in flue gas desulfurization (FGD) systems, paper pulp bleaching equipment, chemical processing vessels, and petrochemical pipelines handling sulfur-bearing acids. The increased addition of molybdenum and chromium ensures long-term operational life where conventional 304 or 316 alloys suffer localized corrosion or stress cracking.
| Product Form | Outer Diameter (OD) | Wall Thickness (WT) | Standard Length |
|---|---|---|---|
| Seamless Pipe (SMLS) | 10.3mm – 610.0mm (1/8" – 24") | 1.24mm – 59.54mm (SCH 5S – SCH 160) | 6m / 12m / Fixed Length |
| Welded Pipe (ERW / EFW) | 15.0mm – 1219.0mm (1/2" – 48") | 1.5mm – 30.0mm (SCH 5S – SCH 80S) | 6m / Cut-to-length |
| Heat Exchanger / Condenser Tube | 9.52mm – 38.1mm | 0.89mm – 3.05mm | Straight 12m / U-Bended |
| Element | Cr | Ni | Mo | C | Mn | Si | P / S | Fe |
|---|---|---|---|---|---|---|---|---|
| Min. | 18.0 | 11.0 | 3.00 | - | - | - | - | Bal. |
| Max. | 20.0 | 15.0 | 4.00 | 0.08 | 2.00 | 0.75 | 0.045 / 0.030 | Bal. |
| Tensile Strength Rm (MPa) | Yield Strength Rp0.2 (MPa) | Elongation A5 (%) | Hardness (HB) | Density (g/cm³) | Melting Range (°C) |
|---|---|---|---|---|---|
| ≥ 515 | ≥ 205 | ≥ 35 | ≤ 217 | 8.00 | 1370 – 1400 |
