Inconel 601 (UNS N06601) seamless and welded pipes are extensively utilized in thermal processing, industrial furnaces, radiant tubes, and petrochemical equipment. Due to its balanced nickel-chromium composition supplemented with aluminum, the alloy forms a tightly adherent oxide scale that resists spalling even under severe thermal cycling conditions.
| Product Form | Outer Diameter (OD) | Wall Thickness (WT) | Standard Length |
|---|---|---|---|
| Seamless Pipe (SMLS) | 6.0mm – 219.1mm (1/8" – 8") | 1.0mm – 20.0mm (SCH 10S – SCH 160) | 6m / 12m / Cut-to-length |
| Welded Pipe (ERW / EFW) | 15.0mm – 610.0mm (1/2" – 24") | 1.5mm – 25.4mm (SCH 5S – SCH 80S) | 6m / 12m / Fixed Length |
| Precision Tubing | 3.0mm – 38.1mm | 0.5mm – 3.0mm | Coil / Straight 6m |
| Element | Ni | Cr | Al | Fe | C | Mn | S | Si | Cu |
|---|---|---|---|---|---|---|---|---|---|
| Min. | 58.0 | 21.0 | 1.00 | Bal. | - | - | - | - | - |
| Max. | 63.0 | 25.0 | 1.70 | Bal. | 0.10 | 1.00 | 0.015 | 0.50 | 1.00 |
| Tensile Strength Rm (MPa) | Yield Strength Rp0.2 (MPa) | Elongation A5 (%) | Hardness (HB) | Density (g/cm³) | Melting Range (°C) |
|---|---|---|---|---|---|
| ≥ 550 | ≥ 220 | ≥ 30 | ≤ 180 | 8.11 | 1360 – 1411 |
