Nickel Alloy Inconel 617 Pipe
Product Detail
Inconel 617 (UNS N06617) seamless and welded pipes are widely specified for gas turbine components, ducting, combustion cans, heat exchangers, and high-temperature chemical processing units. The combination of high nickel, chromium, cobalt, and molybdenum content provides outstanding stability and corrosion resistance under severe high-temperature oxidation and carburization conditions.
Inconel 617 Pipe & Tube Manufacturing Specification
|
Product Form
|
Outer Diameter (OD)
|
Wall Thickness (WT)
|
Standard Length
|
|
Seamless Pipe (SMLS)
|
6.0mm – 219.1mm (1/8" – 8")
|
1.0mm – 20.0mm (SCH 10S – SCH 160)
|
6m / 12m / Cut-to-length
|
|
Welded Pipe (ERW / EFW)
|
15.0mm – 610.0mm (1/2" – 24")
|
1.5mm – 25.4mm (SCH 5S – SCH 80S)
|
6m / 12m / Fixed Length
|
|
Precision Tubing
|
3.0mm – 38.1mm
|
0.5mm – 3.0mm
|
Coil / Straight 6m
|
Chemical Composition of Inconel 617 (UNS N06617) (%)
|
Element
|
Ni
|
Cr
|
Co
|
Mo
|
Al
|
Fe
|
C
|
Ti
|
Si / Mn
|
|
Min.
|
44.5
|
20.0
|
10.0
|
8.0
|
0.8
|
-
|
0.05
|
-
|
-
|
|
Max.
|
-
|
24.0
|
15.0
|
10.0
|
1.5
|
3.0
|
0.15
|
0.6
|
1.0 / 1.0
|
Mechanical & Physical Properties (Room Temperature)
|
Tensile Strength Rm (MPa)
|
Yield Strength Rp0.2 (MPa)
|
Elongation A5 (%)
|
Hardness (HB)
|
Density (g/cm³)
|
Melting Range (°C)
|
|
≥ 655
|
≥ 240
|
≥ 35
|
≤ 210
|
8.36
|
1330 – 1380
|
