Nickel Alloy Inconel 625 Pipe
Product Detail
Inconel 625 (UNS N06625) seamless and welded pipes are critical components in offshore oil & gas platforms, marine engineering, chemical processing systems, aerospace, and flue gas desulfurization equipment. High concentrations of nickel, chromium, molybdenum, and niobium combine to provide exceptional corrosion fatigue strength and immunity to chloride stress cracking.
Inconel 625 Pipe & Tube Manufacturing Specification
|
Product Form
|
Outer Diameter (OD)
|
Wall Thickness (WT)
|
Standard Length
|
|
Seamless Pipe (SMLS)
|
6.0mm – 219.1mm (1/8" – 8")
|
1.0mm – 20.0mm (SCH 10S – SCH 160)
|
6m / 12m / Cut-to-length
|
|
Welded Pipe (ERW / EFW)
|
15.0mm – 610.0mm (1/2" – 24")
|
1.5mm – 25.4mm (SCH 5S – SCH 80S)
|
6m / 12m / Fixed Length
|
|
Precision Tubing
|
3.0mm – 38.1mm
|
0.5mm – 3.0mm
|
Coil / Straight 6m
|
Chemical Composition of Inconel 625 (UNS N06625) (%)
|
Element
|
Ni
|
Cr
|
Mo
|
Nb + Ta
|
Fe
|
C
|
Mn
|
Si
|
Al / Ti
|
|
Min.
|
58.0
|
20.0
|
8.0
|
3.15
|
-
|
-
|
-
|
-
|
-
|
|
Max.
|
-
|
23.0
|
10.0
|
4.15
|
5.0
|
0.10
|
0.50
|
0.50
|
0.40 / 0.40
|
Mechanical & Physical Properties (Room Temperature)
|
Tensile Strength Rm (MPa)
|
Yield Strength Rp0.2 (MPa)
|
Elongation A5 (%)
|
Hardness (HB)
|
Density (g/cm³)
|
Melting Range (°C)
|
|
≥ 827 (Grade 1 Annealed)
|
≥ 414
|
≥ 30
|
≤ 220
|
8.44
|
1290 – 1350
|
